NSIS安装包制作

安装包制作是软件发版的关键步骤，制作安装包的工具很多，总体分为两类：GUI工具（Advanced Installer等）、脚本工具（NSIS、Inno Setup等）。

本人在实际工作中深度使用NSIS，感受到了它的强大；同时，也喜欢Inno Setup更加简明的语法和基于Delphi的扩展开发。

实际案例：打包AutoCAD插件系统

# ========================= 宏定义 =========================
# 安装包相关信息宏定义
!define PRODUCT_NAME "XXX设计系统"
!define EXE_NAME "${PRODUCT_NAME}.exe"
!define PRODUCT_VERSION "1.0.0.0"
!define PRODUCT_PUBLISHER "XXX公司"
!define PRODUCT_LEGAL ""

# AutoCAD插件系统的主启动类库文件
!define MAINDLL "TsyShieldTunnelDesign.dll"
# 需要附带安装的安装包名称
!define TOOLKIT_INSTALLER "XXX工具箱.exe"

# 卸载注册表宏路径定义
!define PRODUCT_UNINST_KEY "Software\Microsoft\Windows\CurrentVersion\Uninstall\${PRODUCT_NAME}"
!define PRODUCT_UNINST_ROOT_KEY "HKLM"

# CAD注册表路径宏定义
!define regACAD2020 "SOFTWARE\Autodesk\AutoCAD\R23.1\ACAD-3001:804"
!define regACAD2021 "SOFTWARE\Autodesk\AutoCAD\R24.0\ACAD-4101:804"


# ========================= 变量定义 =========================
var PREVIOUS


# ========================= 安装包版本信息 =========================
VIProductVersion                    "${PRODUCT_VERSION}"
VIAddVersionKey "ProductVersion"    "${PRODUCT_VERSION}"
VIAddVersionKey "ProductName"       "${PRODUCT_NAME}"
VIAddVersionKey "CompanyName"       "${PRODUCT_PUBLISHER}"
VIAddVersionKey "FileVersion"       "${PRODUCT_VERSION}"
VIAddVersionKey "InternalName"      "${EXE_NAME}"
VIAddVersionKey "FileDescription"   "${PRODUCT_NAME}"
VIAddVersionKey "LegalCopyright"    "${PRODUCT_LEGAL}"


# ========================= NSIS属性 =========================
SetFont "Segoe UI" 9
#SetCompressor lzma
SetCompressor zlib
Name "${PRODUCT_NAME}V${PRODUCT_VERSION}"
OutFile "${PRODUCT_NAME}V${PRODUCT_VERSION}.exe"
InstallDir "$PROGRAMFILES64\${PRODUCT_PUBLISHER}\${PRODUCT_NAME}"
ShowInstDetails show
ShowUnInstDetails show
RequestExecutionLevel admin


# ========================= 外部插件及宏引用 =========================
!include LogicLib.nsh
!include "x64.nsh"
!include "Library.nsh"
!include "WordFunc.nsh"
!define LIBRARY_X64
!include "MUI.nsh"


# ========================= MUI设置 =========================
; MUI Settings
!define MUI_ABORTWARNING
!define MUI_ICON "${NSISDIR}\Contrib\Graphics\Icons\modern-install.ico"
!define MUI_UNICON "${NSISDIR}\Contrib\Graphics\Icons\modern-uninstall.ico"
;!define MUI_WELCOMEFINISHPAGE_BITMAP ".\background.bmp"
; Welcome page
!define MUI_WELCOMEPAGE_TITLE "欢迎使用《${PRODUCT_NAME}V${PRODUCT_VERSION}》安装向导"
!define MUI_WELCOMEPAGE_TEXT "此程序将引导你安装《${PRODUCT_NAME}V${PRODUCT_VERSION}》。\r\n\r\n在安装前建议关闭AutoCAD，从而确保安装程序能够更新相关系统文件，避免在安装后需要重启AutoCAD。\r\n\r\n点击[下一步(N)]继续。"
!insertmacro MUI_PAGE_WELCOME
; Directory page
!define MUI_DIRECTORYPAGE_TEXT_TOP "安装程序将把《${PRODUCT_NAME}V${PRODUCT_VERSION}》安装到以下目录。要安装到另一个目录，请点击[浏览(B)...]并选择其他的文件夹。$\r$\n$\r$\n点击[安装] 开始安装。"
!insertmacro MUI_PAGE_DIRECTORY
; Instfiles page
!insertmacro MUI_PAGE_INSTFILES
; Finish page
!insertmacro MUI_PAGE_FINISH
; Uninstaller pages
!insertmacro MUI_UNPAGE_INSTFILES
; Language files
!insertmacro MUI_LANGUAGE "SimpChinese"
; Reserve files
!insertmacro MUI_RESERVEFILE_INSTALLOPTIONS


# ========================= 安装步骤 =========================
# 卸载已安装的软件
Section "" SecUninstallPrevious
	${If} $PREVIOUS == ""
		Goto Done
	${EndIf}
	;卸载已安装程序（和安装一起更安全）
	RMDir /r "$INSTDIR"
	RMDir /r "$SMPROGRAMS\城轨盾构法隧道设计系统"
	setRegView 64
	DeleteRegKey ${PRODUCT_UNINST_ROOT_KEY} "${PRODUCT_UNINST_KEY}"
	DeleteRegKey HKCU "${regACAD2020}\Applications\${PRODUCT_NAME}"
	DeleteRegKey HKCU "${regACAD2021}\Applications\${PRODUCT_NAME}"
	SetRegView Lastused
	Done:
SectionEnd

# .NET Framework版本检测和安装
Section "" PRESEC
    ;检测.net framework版本
    Call GetNetFrameworkVersion
    Pop $R1
    ${VersionCompare} $R1 '4.8' $1
    ${If} $1 == "2"
        ;安装net framework 4.8
        SetDetailsPrint textonly
        SetDetailsPrint listonly
        SetOutPath "$TEMP"
        SetOverwrite on
        File ".\ndp48-x86-x64-allos-enu.exe"
        ExecWait '$TEMP\ndp48-x86-x64-allos-enu.exe /q /norestart /ChainingPackage FullX64Bootstrapper' $R1
        Delete "$TEMP\ndp48-x86-x64-allos-enu.exe"
    ${EndIf}
SectionEnd

# 安装附带的安装包
Section "" TOOLKITINSTALLER
	SetDetailsPrint textonly
	SetDetailsPrint listonly
	SetOverwrite on
	; 将附带安装包拷贝到临时文件夹
	SetOutPath "$INSTDIR\TOOLKIT"
	File ".\${TOOLKIT_INSTALLER}"
	; 安装
	ExecWait '$INSTDIR\TOOLKIT\${TOOLKIT_INSTALLER} /S'
	; 删除
	Delete "$INSTDIR\TOOLKIT\${TOOLKIT_INSTALLER}"
SectionEnd

# 安装程序
Section "MainSection" SEC01
    SetOutPath "$INSTDIR"
    SetOverwrite ifnewer
    ; 复制文件Release下的所有文件，排除.pdb文件
    File /r /x *.pdb "..\Release\*.*"
    ; 写注册表
    setRegView 64
    ; 为CAD2020安装（先检测是否有该注册项）
    ReadRegStr $1 HKLM "${regACAD2020}" "AcadLocation"
    ${If} $1 != ""
        WriteRegStr HKCU "${regACAD2020}\Applications\${PRODUCT_NAME}" "DESCRIPTION" "${PRODUCT_NAME}"
        WriteRegStr HKCU "${regACAD2020}\Applications\${PRODUCT_NAME}" "LOADER" "$INSTDIR\${MAINDLL}"
        WriteRegDWORD HKCU "${regACAD2020}\Applications\${PRODUCT_NAME}" "LOADCTRLS" 0x2
        WriteRegDWORD HKCU "${regACAD2020}\Applications\${PRODUCT_NAME}" "MANAGED" 0x1
    ${EndIf}
    ; 为CAD2021安装
    ReadRegStr $1 HKLM "${regACAD2021}" "AcadLocation"
    ${If} $1 != ""
        WriteRegStr HKCU "${regACAD2021}\Applications\${PRODUCT_NAME}" "DESCRIPTION" "${PRODUCT_NAME}"
        WriteRegStr HKCU "${regACAD2021}\Applications\${PRODUCT_NAME}" "LOADER" "$INSTDIR\${MAINDLL}"
        WriteRegDWORD HKCU "${regACAD2021}\Applications\${PRODUCT_NAME}" "LOADCTRLS" 0x2
        WriteRegDWORD HKCU "${regACAD2021}\Applications\${PRODUCT_NAME}" "MANAGED" 0x1
    ${EndIf}
    SetRegView Lastused
SectionEnd

# 创建开始菜单项
Section -AdditionalIcons
  SetOutPath $INSTDIR
  CreateDirectory "$SMPROGRAMS\XXX设计系统"
  CreateShortCut "$SMPROGRAMS\XXX设计系统\Uninstall.lnk" "$INSTDIR\uninst.exe"
SectionEnd

# 写入卸载相关的注册表信息
Section -Post
  WriteUninstaller "$INSTDIR\uninst.exe"
  setRegView 64
  WriteRegStr ${PRODUCT_UNINST_ROOT_KEY} "${PRODUCT_UNINST_KEY}" "DisplayName" "$(^Name)"
  WriteRegStr ${PRODUCT_UNINST_ROOT_KEY} "${PRODUCT_UNINST_KEY}" "UninstallString" "$INSTDIR\uninst.exe"
  WriteRegStr ${PRODUCT_UNINST_ROOT_KEY} "${PRODUCT_UNINST_KEY}" "DisplayIcon" ""
  WriteRegStr ${PRODUCT_UNINST_ROOT_KEY} "${PRODUCT_UNINST_KEY}" "DisplayVersion" "${PRODUCT_VERSION}"
  WriteRegStr ${PRODUCT_UNINST_ROOT_KEY} "${PRODUCT_UNINST_KEY}" "Publisher" "${PRODUCT_PUBLISHER}"
  SetRegView Lastused

  ; 设置权限
  ExecWait '"$INSTDIR\SetACL.exe" -on "$INSTDIR\Plugins" -ot file -actn ace -ace "n:everyone;p:full"'
SectionEnd

# 卸载程序
Section Uninstall
	; 删除文件
    RMDir /r "$INSTDIR"
    ; 删除开始菜单项
    RMDir /r "$SMPROGRAMS\XXX设计系统"
    ; 删除注册表
    setRegView 64
    DeleteRegKey ${PRODUCT_UNINST_ROOT_KEY} "${PRODUCT_UNINST_KEY}"
    DeleteRegKey HKCU "${regACAD2020}\Applications\${PRODUCT_NAME}"
    DeleteRegKey HKCU "${regACAD2021}\Applications\${PRODUCT_NAME}"
    SetRegView Lastused
    ; 设置自动关闭卸载窗体
    SetAutoClose true
SectionEnd


# ========================= 回调函数 =========================
# 安装初始化事件处理
Function .onInit
    ; 添加互斥体，防止同时创建多个安装进程
    System::Call 'kernel32::CreateMutex(p 0, i 0, t "myMutex") p .r1 ?e'
    Pop $R0
    StrCmp $R0 0 +3
    MessageBox MB_OK|MB_ICONEXCLAMATION "安装程序已运行。"
    Abort
    ; 检测是否已安装
    setRegView 64
    ReadRegStr $PREVIOUS ${PRODUCT_UNINST_ROOT_KEY} ${PRODUCT_UNINST_KEY} "UninstallString"
    SetRegView Lastused
    ${If} $PREVIOUS == ""
    	Goto Done
    ${EndIf}
	; 已安装，让用户选择是否覆盖安装，否则终止安装
    MessageBox MB_YESNO "检测已安装《${PRODUCT_NAME}》，是否覆盖安装？" IDYES true IDNO false
    true:
    	Goto Done
    false:
    	Abort
    Done:
FunctionEnd

# 卸载初始化事件处理
Function un.onInit
    MessageBox MB_ICONQUESTION|MB_YESNO|MB_DEFBUTTON2 "是否确定彻底卸载 $(^Name)?" IDYES +2
    Abort
FunctionEnd

# 卸载完成事件处理
Function un.onUninstSuccess
    HideWindow
    MessageBox MB_ICONINFORMATION|MB_OK "$(^Name)已从您的电脑上彻底卸载。"
FunctionEnd


# ========================= 用户函数 =========================
# .NET Framework版本检测
Function GetNetFrameworkVersion
    Push $1
    Push $0
    ReadRegDWORD $0 HKLM "SOFTWARE\Microsoft\NET Framework Setup\NDP\v4\Full" "Install"
    ReadRegDWORD $1 HKLM "SOFTWARE\Microsoft\NET Framework Setup\NDP\v4\Full" "Version"
    StrCmp $0 1 KnowNetFrameworkVersion +1
    ReadRegDWORD $0 HKLM "SOFTWARE\Microsoft\NET Framework Setup\NDP\v3.5" "Install"
    ReadRegDWORD $1 HKLM "SOFTWARE\Microsoft\NET Framework Setup\NDP\v3.5" "Version"
    StrCmp $0 1 KnowNetFrameworkVersion +1
    ReadRegDWORD $0 HKLM "SOFTWARE\Microsoft\NET Framework Setup\NDP\v3.0\Setup" "InstallSuccess"
    ReadRegDWORD $1 HKLM "SOFTWARE\Microsoft\NET Framework Setup\NDP\v3.0\Setup" "Version"
    StrCmp $0 1 KnowNetFrameworkVersion +1
    ReadRegDWORD $0 HKLM "SOFTWARE\Microsoft\NET Framework Setup\NDP\v2.0.50727" "Install"
    ReadRegDWORD $1 HKLM "SOFTWARE\Microsoft\NET Framework Setup\NDP\v2.0.50727" "Version"
    StrCmp $1 "" +1 +2
    StrCpy $1 "2.0.50727.832"
    StrCmp $0 1 KnowNetFrameworkVersion +1
    ReadRegDWORD $0 HKLM "SOFTWARE\Microsoft\NET Framework Setup\NDP\v1.1.4322" "Install"
    ReadRegDWORD $1 HKLM "SOFTWARE\Microsoft\NET Framework Setup\NDP\v1.1.4322" "Version"
    StrCmp $1 "" +1 +2
    StrCpy $1 "1.1.4322.573"
    StrCmp $0 1 KnowNetFrameworkVersion +1
    ReadRegDWORD $0 HKLM "SOFTWARE\Microsoft\.NETFramework\policy\v1.0" "Install"
    ReadRegDWORD $1 HKLM "SOFTWARE\Microsoft\.NETFramework\policy\v1.0" "Version"
    StrCmp $1 "" +1 +2
    StrCpy $1 "1.0.3705.0"
    StrCmp $0 1 KnowNetFrameworkVersion +1
    StrCpy $1 "not .NetFramework"
    KnowNetFrameworkVersion:
    Pop $0
    Exch $1
FunctionEnd

关键点总结

• 压缩方式：平衡速度和安装包体积
• 界面语言和字体设置
• 开始菜单和桌面快捷方式设置
• 检测是否已安装软件：通过读相关的注册表信息
• 注册表操作（读、写、删）
• .NET Framework版本检测
• 禁止启动多个安装进程：使用Windows API创建内核对象，实现进程之间的互斥
• 使用SetACL.exe设置目录的用户权限

补充

读写xml配置文件

在进行Revit插件安装时，需要配置addin配置文件，在其中写入真正的插件dll路径。addin文件本质上是一种xml文件，采用以下方式可以动态设置。

注意：需要事先部署好nsisXML插件。

; 复制xml配置文件
SetOutPath "${ADDINPATH}"
File "..\ShieldTunnelRevit\TsyShieldTunnelRevitDesign.addin"
; 修改xml配置文件
nsisXML::create
nsisXML::load ${ADDINPATH}\TsyShieldTunnelRevitDesign.addin
nsisXML::select '/RevitAddIns/AddIn/Assembly'
nsisXML::setText "$INSTDIR\TsyShieldTunnelRevitDesign.dll"
nsisXML::save "${ADDINPATH}\TsyShieldTunnelRevitDesign.addin"
nsisXML::release $0

权限修改

除了上文提到的SetACL.exe程序外，也可以使用AccessControl插件。
